7.18 SC16
Data Sheet Version 1.10 (16 differential analog inputs)
Parameter
Value (typ. / max.)
Remarks
Channels
16
4-channel groups on 4x DSUB-15
Measurement mode (DSUB)
CANSAS-SC16,
CANSAS-L-SC16,
CANSAS-K-SC16
voltage 60 V
voltage 10 V
thermocouple, RTD (Pt100)
current
with divider plug (ACC/DSUB-U4D)
standard plug (ACC/DSUB-U4)
thermo plug (ACC/DSUB-T4)
with shunt plug (ACC/DSUB-I4)
Measurement mode (SL DSUB)
CANSAS-SL-SC16-D
CANSAS-SL-SC16-L-SUPPLY
voltage 10 V
ACC/DSUB-U4-IP65
Measurement mode (SL LEMO)
CANSAS-SL-SC16-L,
CANSAS-SL-SC16-L-SUPPLY
voltage 10 V
RTD (Pt100)
current
with external shunt
Measurement mode (TK-plug)
CANSAS-L-SC16-2T,
CANSAS-L-SC16-2T-Y,
CANSAS-K-SC16-2T
thermocouple type-K
thermocouple type-K
thermocouple type-K
article number: 1050397 (yellow plug)
article number: 1050332
CANSAS-K1-SC16-2T,
CANSAS-K1-SC16-3T
thermocouple type-K
thermocouple type-K
CANSAS-K-SC16-2T
thermocouple type-T
article number: 1050333
TEDS - Transducer Electronic
DataSheets
conform IEEE 1451.4
Class II MMI
ACC/DSUB-TEDS-U4, TEDS-U4D
ACC/DSUB-TEDS-U4-IP65
ACC/DSUB-TEDS-T4, -TEDS-T4-IP65
ACC/DSUB-TEDS-I4, -TEDS-I4-IP65
CANopen mode
"CiA DS 301 V4.0.2" and
"CiA DS 404V1.2"
supports 4 PDOs in
INT16, INT32, and FLOAT
in CANopen mode:
max. 100Hz (10ms) / channel
Sampling rate
CANSAS-SC16
max. 500 Hz (2 ms) / channel
maximum allowable input signal
frequency:
100 Hz
The sampling rates 500Hz and 200Hz are
based on a slower working sampling rate
and will be interpolated.
Sampling rate, temperature
CANSAS-SC16
max. 1 Hz (1 s) / channel
recommended maximum for optimized
noise reduction; filter: 12 Hz (-3 dB);
-60 dB @ 50 Hz
no restrictions for input noise frequency
(except for narrow band 0,5 Hz to 12 Hz)
Bandwidth
with compensation filter
28 Hz
sampling rate / 7
at sampling rate
500 Hz (2 ms), 200 Hz (5 ms)
100 Hz (10 ms) to 2 Hz (500 ms)
Resolution
16 bit
