6.18 SC16, SCI8, SCI16 voltage, current and temp. modes
8/16 differential, analog inputs
Parameter
Value (typ. / max)
Remarks
Channels
imc CANSAS-SC16,
SCI16
imc CANSAS-SCI8
16
8
4-channel groups on 4 x
DSUB-15
4-channel groups on 2 x
DSUB-15
Measurement mode
(DSUB)
imc CANSAS-SCI-8,
SCI-16
imc CANSAS-SC-16
imc CANSAS-SCI-8,
SC(I)-16
voltage 60 V
voltage 10 V
voltage 60 V
thermocouple, RTD (Pt100)
current
standard-plug (ACC/DSUB-
U4)
standard-plug (ACC/DSUB-
U4)
divider-plug (ACC/DSUB-
UD4)
thermo-plug (ACC/DSUB-T4)
shunt-plug (ACC/DSUB-I4)
Measurement mode (SL
DSUB)
imc CANSAS-SL-SC16-D
voltage 10 V
ACC/DSUB-U4-IP65
Measurement mode (SL
LEMO)
imc CANSAS-SL-SC(I)
16-L
imc CANSAS-SL-SCI-8
voltage 10 V
RTD (Pt100)
current
Measurement mode
(TK-plug)
imc CANSAS-L-SC16-
2T,
-L-SCI8-2T, -L-
SCI8-2T-Y,
-K1-SC16-2T
thermocouple, type-K
-Y = yellow, otherwise green
Technical data SC16 and the technical data SCI8 and SCI16
The imc CANSAS modules SCI8, SCI16 and SC16 have 8 or 16 input channels respectively. The modules
belonging to the SCIxx group (SCI8, SCI16) have extended isolation properties, with channel-to-channel
isolation and common mode voltage of up to 60 V (with a test voltage of 300 V). The SC16's isolation
voltage values are limited to 40 V (Common mode voltage and max. protected channel-to channel
isolation) at a working range of channel to channel isolation of 15 V (for specified accuracy).
All SC variants (from March, 2006) support TEDS to read and write sensor information.
Beside working with CAN-bus per default, the modules are also configurable as CANopen modules.
