6.13.1 Connector plugs ISO8
For the pin assignment of the DSUB-15 plugs see here .
Connections to imc CANSAS-K-ISO8-BNC are made with BNC sockets. imc CANSAS-K-ISO8-T2 and imc
CANSAS-K-ISO8-T3 come with two- or three-pin TK-sockets.
