550 Pin configuration and power supply
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
8.3.4 Pin configuration DSUB-9 connectors
8.3.4.1 CANSAS-K-INC4
DSUB-9 Pin
CON1
CON2
CON3
CON4
1
+IN1X
+IN2X
+IN3X
+IN4X
6
-IN1X
-IN2X
-IN3X
-IN4X
2
+IN1Y
+IN2Y
+IN3Y
+IN4Y
7
-IN1Y
-IN2Y
-IN3Y
-IN4Y
3
+INDEX
2
+INDEX
+INDEX
+INDEX
8
-INDEX
-INDEX
-INDEX
-INDEX
4
NC
NC
NC
NC
9
GND
GND
GND
GND
5
+5V
+5V
+5V
+5V
2
The incremental counter inputs have a common index track, which is connected in parallel to the other inputs in
each DSUB.
