164 Virtual Channels
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
Description: Disjunction operation performed on two channels. The return value is 1 whenever one of
the sample values from the two channels is nonzero. Otherwise, the return value is 0. Therefore, one of
the following two conditions must be fulfilled so that the return value is 1:
u [k] 0 or v [k] 0
where k is a serial index, and v are the two input channels.
Note: Both channels must share the same sampling rate.
Data types:
4.10.40 Logical exclusive OR
Channel whose sample values are disjunctioned with the respective value from the
2nd parameter
Channel whose sample values are disjunctioned with the respective value from the
1st parameter
Digital channel containing the disjunction results.
Description: Exclusive disjunction operation performed on two channels. The return value is 1 whenever
the corresponding sample values from each of the two channels are logically opposites. Otherwise, the
return value is 0. Therefore, one of the following two conditions must be fulfilled so that the return value
is 1:
(u [k] = 0 and v [k] 0) or (u [k] 0 and v [k] = 0)
where k is a serial index, and v are the two input channels.
Notes: Both channels must share the same sampling rate.
Data types:
