7.19 SCI8, SCI16
Data Sheet Version 1.10
Parameter
Value
Remarks
Channels
CANSAS-SCI16
CANSAS-SCI8
16
8
4-channel groups on 4x DSUB-15
4-channel groups on 2x DSUB-15
Measurement mode
DSUB
thermocouple, RTD (PT100)
current
standard-plug (ACC/DSUB(M)-U4)
thermo-plug (ACC/DSUB(M)-T4)
shunt-plug (ACC/DSUB(M)-I4)
Measurement mode
LEMO
RTD (PT100)
current
with external shunt
Measurement mode
Thermo
thermocouple type-K
-Y = yellow
Measurement mode
BNC
Sampling rate, Bandwidth, CANopen®, TEDS
Parameter
Value
Remarks
Sampling rate
CANSAS-SCI16
CANSAS-SCI8
max. 500 Hz (2 ms) / channel
max. 1 kHz (1 ms) / channel
max. allowable input signal frequency:
100 Hz
150 Hz
Sampling rate, Temperature
CANSAS-SCI16
CANSAS-SCI8
max. 1 Hz (1 s) / channel
max. 2 Hz (500 ms) / channel
recommended maximum for optimized
noise reduction; filter:
12 Hz (-3 dB); -60 dB @ 50 Hz
no restrictions for input noise frequency
(except for narrow band 0.5 Hz to 12 Hz)
Bandwidth
CANSAS-SCI16
CANSAS-SCI8
with compensation filter
23 Hz
sampling rate / 7
42 Hz
sampling rate / 7
at sampling rate
500 Hz (2 ms), 200 Hz (5 ms)
100 Hz (10 ms) to 2 Hz (500 ms)
1 kHz (1 ms), 500 Hz (2 ms)
200 Hz (5 ms) to 5 Hz (200 ms)
Resolution
16 bit
CANopen mode
"CiA DS 301 V4.0.2" and
"CiA DS 404V1.2"
supports 4 PDOs in
INT16, INT32, and FLOAT
SCI16: in CANopen mode:
max. 100 Hz (10 ms) / channel
SCI8: in CANopen mode:
max. 200 Hz (5 ms) / channel
TEDS - Transducer
Electronic Data Sheets
conform IEEE 1451.4
Class II MMI
ACC/DSUB(M)-TEDS-xxx
