500 General Technical Specs
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
General
Parameter
typ.
min. / max.
Remarks
78 x 112.5 x 152 mm
58 x 112.5 x 152 mm
55 x 111 x 90 mm
55 x 111 x 145 mm
58 x 112.5 x 152 mm
78 x 112.5 x 152 mm
CANSAS-SL-SC16-L
CANSAS-SL-SC16-D
with optional sensor supply
CANSAS-SC16-SUPPLY
CANSAS-L-SC16-SUPPLY
CANSAS-SL-SC16-L-SUPPLY
CANSAS-SL-SC16-D-SUPPLY
Terminal connection
4x DSUB-15
16x 2-pol. TK-connector
inputs CANSAS-SC16
only for thermocouple type K
2x DSUB-9
CAN (in / out), power supply
(alternatively)
PHOENIX (MC 1,5 /4STF-3,81)
DC power supply
Terminal connection SL
4x DSUB-15
16x LEMO (HGG.1B.307)
inputs
CANSAS-SL-SC16-D(-SUPPLY)
CANSAS-SL-SC16-L (-SUPPLY)
2x DSUB-9
2x 10-pin LEMO (HGA.1B.310
power supply (alternatively)
CANSAS-SL-SC16-D(-SUPPLY)
CANSAS-SL-SC16-L (-SUPPLY)
1x 6-pin LEMO (HGA.1B.306)
power supply (for all SL models)
