General
Parameter
typ.
min. / max.
Remarks
Block isolation:
CAN-bus
DC supply input
60 V
60 V
each function block to case (CHASSIS)
nominal; testing: 300 V (10 s)
nominal; testing: 300 V (10 s)
Max. common-mode input
voltage
40 V
analog input to case (CHASSIS)
nominal rating
Channel isolation:
CAN-bus
supply
15 V
40 V
max. voltage between any two arbitrary
input pins of different channels;
for specified accuracy
fault protection
Overvoltage protection
40 V
differential channel input voltage
(long-term)
Input configuration
DC, differential
isolated to:
case, supply and CAN-bus
Input impedance (static)
10 M
1 M
50
voltage mode 10 V
voltage mode 20 V (divider)
current mode (Shunt plug)
Input current :
static
dynamic
on overvoltage condition
2 nA (typ.)
0.2 mA (typ.)
20 nA (typ.)
0.1 µA
25 nA (max.)
20 mA (max.)
2 µA (max.)
1 µA
dynamic input currents: scanner-device!
settled current at time of sampling
peak dynamic input current
(typ. @100 mV, max. @10 V)
average dynamic input current
(typ. @100 mV, max. @10 V)
|Vin| >15 V ;or device powered-down
Noise
25 V pk-pk
10 mV pk-pk
0.5 K pk_pk
6 V pk-pk
5 V rms
2 mV rms
0.08 K rms
sample-rate: 2 ms, R_s = 50
range ±100 mV
range ±20 V
temperature mode: Thermocouple Type K
sample-rate: 1 s, R_s = 50
Source impedance
5 k (max.)
of sensor or signal source
Cable length (signal-input)
200 m (max.)
100 pF / m
Crosstalk (channel to channel)
<-105 dB
60 Hz, 100 source impedance,
range 100 mV
CMRR / IMR
100 dB (50 Hz)
Common-Mode reference: frame
(CHASSIS)
all other channels: CHASSIS
Supply voltage
10 V to 50 V DC
sensor supply voltage
(optional)
2.5 V to 24 V
technical specs Sensor supply module
Power requirements:
2.6 W (typ.)
<3.0 W (max.)
12 V DC, over full temperature range
Operating temperature
-30°C to 85°C
Dimensions (W x H x D), weight
55 x 111 x 90 mm; 300 g
55 x 111 x 145 mm; 850 g
41 x 128 x 145 mm; 500 g
81 x 128 x 145 mm
CANSAS-SC16
CANSAS-L-SC16, -L-SC16-2T
CANSAS-K-SC16, -K(1)-SC16-2T
CANSAS-K1-SC16-3T
