6.20.9 Bandwidth
The channels' maximum sampling rate is 1 kHz(1 ms).
The analog bandwidth (without digital low-pass filtering) is 200 Hz
6.20.10 Connection
The analog channels are equipped with DSUB-15 plugs (CANSAS-x-UNI8-D), ITT-VEAM-plugs (CANSAS-x-
UNI8) or LEMO-plugs (CANSAS-x-UNI8-L)ITT-VEAM-plugs (C1) or LEMO-plugs (C1-1-LEMOSA).
In the connection diagrams, the numbering for LEMO and custom ITT VEAM connectors appear alongside
of the labeling in the terminals:
LEMO
ITT-VEAM
imc-plug ACC/DSUB-UNI2 or -B2
1
A
+IN
2
B
-IN
3
C
+VB
4
D
-VB
5
E
TEDS (OneWire)
6
F
sense
7
G
Quarter bridge completion / sense for Pt100 3-wire configuration
Find here the pin configuration of the DSUB-15 plugs , ITT-VEAM-plugs and the LEMO-plugs .
