Measurement modes 181
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
Measurement Technique
5.1 Measurement modes
5.1.1 Bridge modules
With the modules imc CANSAS-BRIDGE2, -DCB8, -UNI8, imc µ-CANSAS-B1 or imc µ-CANSAS-B4 a bridge
measurement can be carried out.
5.1.1.1 General remarks
Bridge channels are for taking readings from measurement bridges such as resistor bridges or strain
gauges. The channels are equipped as non-isolated differential amplifiers and can alternatively be used
for direct measurement of voltages.
There is a distinction among the following operating modes:
1. Target: Sensor
Full bridge
Half bridge
Quarter bridge (120 )
1. Target: Strain gauge
Full bridge with 4 active strain gauges in uniaxial direction
Full bridge with Poisson strain gauge in adjacent bridge arms
Full bridge with Poisson strain gauge in opposing bridge arms
Half bridge with one active and one passive strain gauge
Half bridge with 2 active strain gauges in uniaxial direction
Poisson half bridge
Quarter bridge with 120 strain gauge
Note
The following discussion, whenever it is in reference to terminal connections, circuitry etc.,
pertains only to the imc CANSAS-BRIDGE2 module, and only the most general remarks on bridge
measurement are applicable for bridge measurement systems besides UNI8 and DCB8. Such
generalized topics include instrument sensitivity and strain gauge properties.
