7.6 DAC8
Data Sheet Version 1.5 (8 analog outputs)
Parameter
Value (typ./max.)
Remarks
Channels
8
Configuration options
voltage source
current source
each channel configurable separately
Output range
-10 V to +10 V
0 mA to 20 mA
(connected to min. 1 k for voltage mode)
(connected to max. 250 for current
mode)
Sampling rate
5 kHz (max.)
Analog bandwidth
5 kHz
-3 dB
Resolution
16 bit
15 bit
as voltage source
as current source
Accuracy deviation
<0.1 %
Output value upon power-up
0 V
CAN-Bus
defined as per ISO 11898
Isolation:
CAN-Bus
power supply
analog outputs
60 V
60 V
no isolation
to CHASSIS
nominal; testing voltage: 300 V (10 s)
nominal; testing voltage: 300 V (10 s)
analog reference ground: CHASSIS
Supply voltage
10 V to 50 V DC
Power consumption
6 W (typ.)
12 V supply, 23°C
Operating temperature
-20°C to 85°C
CANopen mode
"CiA DS 301 V4.0.2" and
"CiA DS 404V1.2"
supports 4 RPDOs in
INT16, INT32, and FLOAT
Dimensions (W x H x D)
35 x 111 x 90 mm
35 x 111 x 145 mm
41 x 128 x 145 mm
75 x 111 x 145 mm
CANSAS-DAC8
CANSAS-L-DAC8
CANSAS-K-DAC8, -K-DAC8-BNC (8TE)
CANSAS-L-DAC8-V
Weight
300 g
for CANSAS-DAC8
Connection terminals
2x DSUB-15
8x BNC
8x ITT Veam
2x DSUB-9
PHOENIX (MC 1.5/4STF-3.81)
outputs DAC8, -L-DAC8
–K-DAC8
–K-DAC8-V
CAN (in/out)
supply
Connection terminals for SL
2x DSUB-15 / 4 channels
2x DSUB-9
1x 6-pin LEMO (HGA.1B.306)
CANSAS-SL-DAC8-D
CAN (in/out), power supply (alternatively)
DC supply for all SL models
Module description DAC8
