472 General Technical Specs
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
Power supply of the module
Parameter
Value
Remarks
Input supply voltage
10 V to 50 V DC
Power-consumption of
analog conditioning
<5.5 W
<10 W
without supply
with supply (supply is optional, but not the
±15 V variant)
Operating conditions and terminal connections of the module
Parameter
Value
Remarks
Operating temperature
-30°C to 85°C
Dimensions (W x H x D)
55 x 111 x 145 mm
41 x 128 x 145 mm
58 x 112.5 x 152 mm
38 x 112.5 x 152 mm
78 x 112.5 x 152 mm
58 x 112.5 x 152 mm
CANSAS-L-CI8(-SUPPLY), -2T, -BNC
CANSAS-L-CI8-V(-SUPPLY)
CANSAS-K-CI8, -BNC, -PH, -2T
CANSAS-SL-CI8-L
CANSAS-SL-CI8-D
CANSAS-SL-CI8-L-SUPPLY
CANSAS-SL-CI8-D-SUPPLY
Weight
approx. 800 g
approx. 450 g
approx. 600 g
aluminum housing (CANSAS-L)
cassette (CANSAS-K)
SL housing
Terminal connection
CANSAS-K, -L
8x ITT-Veam (VPT02Y10-7S)
or
8x 7-pin LEMO (HGG.1B.307)
or
2x DSUB-15
or
8x BNC
or
8x Thermocouple type-K
or
4x 8-pin Phoenix plug
(Typ MC1,5/8-GF-3,5)
2x DSUB-9
PHOENIX (MC 1.5/4STF-3.81)
4 channels per plug
8 channels per plug (CANSAS-K-CI8-PH)
CAN (in / out), power supply (alternatively)
DC power supply
Terminal connection
CANSAS-SL
8x Litton-Veam (VPT02Y10-7S)
or
8x 10-pin LEMO (HGA.1B.310)
or
2x DSUB-15
2x 10-pin LEMO (HGA.1B.310)
1x 6-pin LEMO (HGA.1B.306)
CANSAS-SL-CI8-LV-SUPPLY
4 channels per plug
CAN (in / out), power supply (alternatively)
DC power supply
Module description CI8
275
