Power supply of the module
Parameter
Value
Remarks
Supply voltage
10 V to 50 V DC
Power consumption
4 W to 18 W
Operating temperature
-40°C to 85°C
Dimensions (W x H x D)
75 x 111 x 142 mm
81 x 128.4 x 145 mm
58 x 112.5 x 152mm
CANSAS-L-DCB8
CANSAS-K-DCB8
CANSAS-SL-DCB8-D, -Protect, -SL-DCB8-L
Terminal connection
CANSAS-K, -L
8x 7-pin LEMO (HGG.1B.307)
4x DSUB-15
2 channels per plug
2x DSUB-9
CAN (in / out), supply (alternatively)
PHOENIX (MC 1.5/4STF-3.81)
power supply
Terminal connection
CANSAS-SL
8x 7-pin LEMO (HGG.1B.307)
4x DSUB-15
2 channels per plug
2x DSUB- 9
2x 10-pin LEMO (HGA.1B.310)
CAN (in / out), supply (alternatively)
CAN (in / out), supply (alternatively)
1x 6-pin LEMO (HGA.1B.306)
power supply
Module description DCB8
