226 Measurement Technique
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
PWM8: special feature from production date
UNI8: special feature from production date
Pt100 inside the
connector
Sensor recognition by
jumper configuration
SCI8, SCI16, SC16: special feature from production date
Sensorkennung / imc SENSORS
Description of features
The Eprom (TEDS) with slot recognition is readable (and writable).
The data acquisition modules work in synchronization, i.e. the sampling is
simultaneous. See the section Synchronization .
A module’s configuration can be saved to the module in a way which can be read
back. This means that the configuration can be imported from the module when it
is integrated into the system. See Extras - Options .
DAC8: outputs each set for I/
U separately
The DAC8’s output channels can each be switched separately between voltage
and current. If the feature is not available, then it is only possible to switch
between voltage and current for the entire module.
The Eprom of the sensor connected is readable. The data it contains can be used
to make settings for the channels.
Only for UNI8: measurement bridges can be connected.
The module is connected with the sensor database imc-Sensors. The data it
contains can be used to make settings for the channels.
UNI8: sensor recognition by
jumper configuration
A shorting jumper inside the connector is used to detect a Type K thermocouple.
UNI8: Pt100 inside the
connector
Only for UNI8: With thermocouple measurement, the temperature of the cold
junction point can also be measured inside the connector by placing a Pt100
inside the connector.
UNI8: current with built-in
120 resistor
Single-end current measurement with a 120 resistor built into the module
Connection and measurement of a 350 ¼-bridge is possible.
Connection and measurement of a 120 ¼-bridge is possible.
125
104
