482 General Technical Specs
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
Parameter
Value (typ. / max)
Remarks
Gain uncertainty
<±5 mV
<±10 mV
-30° - 85°C
Offset uncertainty
<±2 mV
<±4 mV
-30° - 85°C
Digital outputs
Level
TTL
representation of all input signals
General
CAN-Bus
defined by ISO 11898
Isolation:
CAN-Bus
analog input
60 V
60 V
to case(CHASSIS)
nominal; testing voltage: 300 V (10 s)
nominal; testing voltage: 100 V (10 s)
Sensor supply
+12 V ( max 100 mA)
+5 V ( max 200 mA)
Reference: GND
Display
2 lines
0.2 s, 0.5 s, 1 s
alphanumerical
frame rate
Supply voltage
10 V to 30 V DC
Power consumption
4 W (typ.)
12 V supply, 23°C
Operating temperature
-30°C to 85°C
typically, display can be read in
temperatures above 15°C
Dimensions (W x H x D)
205 x 115 x 45 mm
imc CANSAS-IGN
Weight
800 g
Connection terminals
4xBNC
1x DSUB-15
2x DSUB-9
PHOENIX (MC 1,5/4STF-3,81)
inputs
outputs
CAN (in / out)
power supply
Module description IGN
310
