484 General Technical Specs
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
Parameter
Value
Remarks
Sensor supply voltage at
CANSAS-L-INC4-V-SUPPLY
+2.5 V to +24 V
technical specs:
Sensor supply module
Power consumption:
4 W (typ.)
12 V supply, 23°C
Operating temperature
-30°C to 85°C
Dimensions (W x H x D)
35 x 111 x 90 mm
35 x 111 x 145 mm
41 x 128 x 145 mm
38 x 112.5 x 152 mm
38 x 112.5 x 152 mm
CANSAS-INC4
CANSAS-L-INC4, -L-INC4-V
CANSAS-C-INC4 (8TE)
CANSAS-SL-INC4-L
CANSAS-SL-INC4-D
Weight
300 g
CANSAS-INC4
Connection terminals
2x DSUB-15
4x ITT VEAM
2x DSUB-9
2x DSUB-9
PHOENIX (MC 1,5/4STF-3,81)
Inputs: -INC4, -L-INC4
-L-INC4-V(-SUPPLY)
-K-INC4
CAN (in / out), supply (alternatively)
power supply
Connection terminals for SL
inputs
CAN (in/out)
inputs
CAN (in/out)
power supply
2x DSUB-15
2x DSUB-9
CANSAS-SL-INC4-D
power supply (alternatively)
4x 7-pin LEMO (HGG.1B.307)
2x 10-pin LEMO (HGA.1B.310)
1x 6-pin LEMO (HGA.1B.306)
only CANSAS-SL-INC4-L
power supply (alternatively)
for all SL models
Module description INC4
518
334
