486 General Technical Specs
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
Parameter
Value (typ. / max)
Remarks
Gain uncertainty:
<0.05 %
<0.15 %
<0.15 %
23°C
with voltage plug
with divider plug
shunt plug
Gain drift
<75 ppm / K
Offset
<0.02 %
across entire temperature range
Temperature uncertainty
<1 K
sensor: Type K at 20 °C
throughout entire temperature range
Noise
50 V pp
25 mV pp
7 V rms
7 mV rms
range 100 mV, Rsource = 50 ,
sampling rate 2ms
range 10 mV (divider)
CMRR / IMR
> 100 dB (50Hz)
±50 V (channel - chassis)
±100 V (channel - channel)
Supply voltage
9 V to 32 V DC
Power consumption::
<2.8 W (typ.)
<3.4 W (max.)
12 V, throughout entire temperature
range
Operating temperature
-30°C to 85°C
Dimensions (W x H x D)
35 x 111 x 90 mm
75 x 111 x 145 mm
40 x 128 x 145 mm
CANSAS-ISO8
CANSAS-L-ISO8-BNC, -L-ISO8-T
CANSAS-K-ISO8, K-ISO8-BNC,
K-ISO8-T2, -K-ISO8-T3
Weight
300 g
Module description ISO8
