General
Parameter
Value typ.
min. / max.
Remarks
Transient protection:
automotive load dump
ISO 7637, test impulse 6
Test impulse 6
Ri=30 , td=300 µs, tr<60 µs
IMR (isolation mode rejection)
>105 dB (50 Hz)
0.01 ppm/Hz
40 dB
>70 dB (50 Hz)
0.12 ppm/Hz
18 dB
Ranges 2 V
< 1 MHz
1 MHz
Ranges 5 V
< 1 MHz
1 MHz
R
source
= 0
Input coupling
configuration
DC
differential, isolated
isolated from system ground
(housing, CHASSIS, function ground)
Input impedance
6.7 M
1 M
50
Ranges 2 V
Ranges 5 V
and with device deactivaed
current input
Input current
normal
at overload
1 nA
1 mA
under operating conditions
|Vin| > 5 V for ranges < 5 V
or deactivated
TEDS - Transducer Electronic
Data Sheets
conformant to IEEE 1451.4
Class II MMI
special order
only when equipped with custom
connectors
CANopen mode
"CiA DS 301 V4.0.2" and
"CiA DS 404V1.2"
supports 4 TPDOs in
INT16, INT32, and FLOAT
from CANSAS version 1.6R12
Supply voltage
10 V to 50 V DC
common mode
Power consumption
4 W
< 5.5 W
depending on supply voltage and
operating mode
Operating temperature
-30°C to 85°C
Dimensions (W x H x D)
Weight
75 x 111 x 145 mm
790 g
tested in this mounting orientation
CANSAS-L-HCI8
CANSAS-L-HCI8
Module description: HCI8
341
