504 General Technical Specs
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
General
Parameter
Value (typ. / max)
Remarks
Input supply voltage
10 V to 50 V DC
Power requirements:
CANSAS-SCI8
CANSAS-SCI16
2.8 W (typ.)
9.0 W (typ.)
<3.3 W (max.)
<10.5 W (max.)
12 V DC, over full temperature range
Operating temperature
-40°C to 85°C
Dimensions (W x H x D), weight
55 x 111 x 90 mm, ca. 500 g
35 x 111 x 90 mm, ca. 330 g
55 x 111 x 145 mm, ca. 850 g
35 x 111 x 145 mm
41 x 128 x 145 mm, ca. 500 g
81 x 128 x 145 mm
58 x 112.5 x 152 mm
78 x 112.5 x 152 mm
38 x 112.5 x 152 mm
58 x 112.5 x 152 mm
55 x 111 x 90 mm
55 x 111 x 90 mm
55 x 111 x 145 mm
55 x 111 x 145 mm
41 x 128 x 145 mm, ca. 500 g
58 x 112.5 x 152 mm
78 x 112.5 x 152 mm
58 x 112.5 x 152 mm
78 x 112.5 x 152 mm
CANSAS-SCI16
CANSAS-SCI8
CANSAS-L-SCI16, L-SCI16-2T
CANSAS-L-SCI8
CANSAS-K-SCI8(16), K-SCI8-2T,
-K-SCI8-BNC (=3HE/8TE)
CANSAS-K-SCI16-2T
-K-SCI16-BNC (=3HE/16TE)
CANSAS-SL-SCI8-L
CANSAS-SL-SCI16-L
CANSAS-SL-SCI8-D
CANSAS-SL-SCI16-D
with optional sensor supply
CANSAS-SCI16-SUPPLY
CANSAS-SCI8-SUPPLY
CANSAS-L-SCI16-SUPPLY
CANSAS-L-SCI8-SUPPLY
CANSAS-K -SCI8(16)-SUPPLY
(=3HE/8TE)
CANSAS-SL-SCI8-L-SUPPLY
CANSAS-SL-SCI16-L-SUPPLY
CANSAS-SL-SCI8-D-SUPPLY
CANSAS-SL-SCI16-D-SUPPLY
Terminal connection
4x DSUB-15
2x DSUB-15
8(16)x 2-pin Thermo-plug
8(16)x BNC
inputs (CANSAS-SCI16)
inputs (CANSAS-SCI8)
thermocouples type-K (CANSAS-X-2T)
inputs (CANSAS-K-SCI8(16)-BNC)
2x DSUB-9
CAN (in / out), power supply (alternatively)
PHOENIX (MC 1,5 /4STF-3,81)
DC power supply
Terminal connection for SL
2(4)x DSUB-15
8(16)x LEMO (HGG.1B.307)
inputs
CANSAS-SL-SCI8(16)-D(-SUPPLY)
CANSAS-SL-SCI8(16)-L(-SUPPLY)
2x DSUB-9
2x 10-pin LEMO (HGA.1B.310)
CAN (in / out) power supply (alternatively)
CANSAS-SL-SCI8(16)-D(-SUPPLY)
CANSAS-SL-SCI8(16)-L(-SUPPLY)
1x 6-pin LEMO (HGA.1B.306)
DC power supply
Module description SCI8, SCI16
371
