510 General Technical Specs
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
General
Parameter
Value typ.
min. / max.
Remarks
Isolation:
CAN-bus
power supply input
analog inputs
60 V
60 V
no isolation
to housing (CHASSIS)
nominal; tested:300 V (10 s)
nominal; tested:300 V (10 s)
analog reference ground: CHASSIS
Supply voltage
10 V to 50 V DC
Power consumption:
5 W (typ.)
8 W (max.)
14 W (max.)
including supply for external sensors
(over total temp. range)
Operating temperature
-40°C to 85°C
Dimensions (W x H x D)
75 x 111 x 145 mm
81 x 128.4 x 145 mm
58 x 112.5 x 152 mm
without plugs
CANSAS-L
CANSAS-K
CANSAS-SL
Weight
ca. 900 g
Connection terminals
CANSAS-K, -L
8x ITT VEAM
or
8x 7-pin LEMO (HGG.1B.307)
or
4x DSUB-15
2 channels per plug
2x DSUB-9
CAN (in / out), supply (alternatively)
PHOENIX (MC 1.5/4STF-3.81)
power supply
Connection terminals
CANSAS-SL
8x ITT VEAM
or
8x 7-pin LEMO (HGG.1B.307)
or
4x DSUB-15
2 channels per plug
2x DSUB- 9
or
2x 10-pin LEMO (HGA.1B.310)
CAN (in / out), supply (alternatively)
CAN (in / out), supply (alternatively)
1x 6-pin LEMO (HGA.1B.306)
power supply
Module description UNI8 .
