µ-CAN - V1/V4 513
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
Parameter
Value
Remarks
Dimensions (W x H x D)
with / without terminal
connection
40 x 20 x 104 / 60 mm
40 x 20 x 114 / 70 mm
55 x 63 x 89 / 70 mm
µ-CANSAS-V1-AS
µ-CANSAS-V1-L
µ-CANSAS-V4-AS
Weight
0.08 kg
0.1 kg
0.26 kg
µ-CANSAS-V1-AS
µ-CANSAS-V1-L
µ-CANSAS-V4-AS
Terminal connection
Sensor
CAN, Supply
1x 8-pin Phoenix strip terminal (MPT0,5/8)
1x 22-pin Autosport Type: AS212-35SN
1x 6-pin Autosport Type: AS208-35PA
2x 5-pin LEMO Type: HGG.0B.305
1x 6-pin Autosport Type: AS208-35PA
1x 6-pin Autosport Type: AS208-35SA
µ-CANSAS-V1
µ-CANSAS-V4-AS
µ-CANSAS-V1-AS CAN OUT
µ-CANSAS-V1-L CAN IN and OUT
µ-CANSAS-V4-AS CAN IN
µ-CANSAS-V4-AS CAN OUT
CANopen® mode
"CiA DS 301 V4.0.2" and
"CiA DS 404V1.2"
supports 1 PDO in
INT16, INT32, and FLOAT
only with µ-CANSAS-V1
TEDS - Transducer Electronic
DataSheets
conforming to IEEE 1451.4
Class II MMI
Module description µ-CANSAS-V1 and µ-CANSAS-V4 .
