Mitsubishi FR-A800

Parameter List
Parameter list (by parameter number)
142
PARAMETERS
Calibration parameters
C9
(930)

M331
Current output bias current 0 to 100% 0.1% - 0% 375
C10
(931)

M332
Current output gain signal 0 to 100% 0.1% - 100% 375
C11
(931)

M333
Current output gain current 0 to 100% 0.1% - 100% 375
C38
(932)

T410
Terminal 4 bias command (torque) 0 to 400% 0.1% 0% 421
C39
(932)

T411
Terminal 4 bias (torque) 0 to 300% 0.1% 20% 421
C40
(933)

T412
Terminal 4 gain command (torque) 0 to 400% 0.1% 150% 421
C41
(933)

T413
Terminal 4 gain (torque) 0 to 300% 0.1% 100% 421
C42
(934)

A630
PID display bias coefficient 0 to 500, 9999 0.01 9999 514
C43
(934)

A631
PID display bias analog value 0 to 300% 0.1% 20% 514
C44
(935)

A632
PID display gain coefficient 0 to 500, 9999 0.01 9999 514
C45
(935)

A633
PID display gain analog value 0 to 300% 0.1% 100% 514

977 E302
Input voltage mode selection 0, 1 1 0 266

989 E490
Parameter copy alarm release
10

1
10

632
100
 100 
PU
990 E104
PU buzzer control 0, 1 1 1 261
991 E105
PU contrast adjustment 0 to 63 1 58 261
Monitor
function
992 M104
Operation panel setting dial push
monitor selection
0 to 3, 5 to 14,
17 to 20, 22 to 35, 38,
40 to 45, 50 to 57, 61,
62, 64, 67, 87 to 98,
100
10 359
Droop
control
994 G403
Droop break point gain 0.1 to 100%, 9999 0.1% 9999 628
995 G404
Droop break point torque 0.1 to 100% 0.1% 100% 628

997 H103
Fault initiation 0 to 255, 9999 1 9999 342

998 E430
PM parameter initialization
0, 3003, 3103, 8009,
8109, 9009, 9109
10 172

999 E431
Automatic parameter setting
1, 2, 10, 11, 12, 13,
20, 21, 9999
1 9999 271

1000 E108
Parameter for manufacturer setting. Do not set.

1002 C150
Lq tuning target current adjustment
coefficient
50 to 150%, 9999 0.1% 9999 452
Additional
function
1003 G601
Notch filter frequency 0, 8 to 1250 Hz 1 Hz 0 208
1004 G602
Notch filter depth 0 to 3 1 0 208
1005 G603
Notch filter width 0 to 3 1 0 208
Clock
function
1006 E020
Clock (year) 2000 to 2099 1 2000 257
1007 E021
Clock (month, day) 1/1 to 12/31 1 101 257
1008 E022
Clock (hour, minute) 0:00 to 23:59 1 0 257

1015 A607
Integral stop selection at limited
frequency
0, 1, 10, 11 1 0 501
Function
Pr.
Pr.
group
Name Setting range
Minimum
setting
increments
Initial value
Refer
to
page
Customer
setting
FM CA
Simple
Simple
Simple
Simple
Simple
Simple
