Autopilot system 8 Vehicle guidance setup
The instructions for this calibration test include several screens. Follow the instructions on each
screen.
Tracked vehicle steering wheel calibration
1. Turn off the engine, but keep the ignition key in the run position.
2. At the Autopilot Calibration screen, select Steering Interface Calibration.
3. Keep to the suggested time interval and follow the on screen instructions to turn the steering
wheel right and left, full lock.
4. Follow the on-screen instructions until Calibration Complete displays on screen.
Autopilot system setup
Note – Autopilot system setup is usually done when the system is professionally installed.
Prior to setup, the Autopilot system must be installed on the FM-1000 integrated display.
There are two stages to set up the Autopilot system:
1. Set up the vehicle. See .
2. Calibrate the Autopilot automated steering system for your vehicle.
Note – The following configuration steps are usually done when the system is professionally installed.
Vehicle controller setup
1.
At the Home screen, tap . The Current Configurations screen displays.
2. Tap Configure.
3.
Select Autopilot (Vehicle) and then tap Setup. The Vehicle Calibration screen displays.
4. On the Vehicle tab, complete the settings as appropriate.
Setting Explanation
Connector Select the port on the FM-1000 integrated display that the
Autopilot system controller is connected to.
Current Select The current vehicle (.vdb) profile that is loaded on the display.
To change this setting, see
Autopilot system setup (page 186)
.
5.
Tap the Engage tab and complete the appropriate settings.
186 FM-1000 Integrated Display User Guide Version 9.25, Revision B
