6/02
2-136
DC1632/2240
8-900
Prelaunch Training/Review
Status Indicator RAPs
8-900 Static Jam
When the machine power is turned off then on before a paper path fault is cleared, an 8-900
fault will be displayed. A voltage drop or interruption can also cause this fault.
Initial Actions
ï Check the entire paper path for paper or obstructions.
ï Clean all the paper path sensors.
ï Check the Fault History for the last paper path fault. Go to that paper path fault RAP.
Procedure
In sequence, enter the following dC330 codes:
Block and unblock each sensor
ï 8-100 Tray 1 Mis-feed, (7-105).
ï 8-106 Tray 2 Mis-feed, (7-110).
ï 8-102 Tray 3 Mis-feed, (7-115).
ï 8-103 Tray 4 Mis-feed, (7-119).
ï 8-104 Registration Sensor, (8-175).
ï 9-201 POB On Jam, (8-164)
The display for each code changes.
YN
Go to the appropriate paper path fault RAP.
Check the machine input voltage, if the problem continues, replace the ESS PWB (PL 13.1).
To Next Page
