Xerox DocuColor 1632 Service Manual

6/02
6-69
DC1632/2240
dC301
General Procedures and Information
Prelaunch Training/Review
dC301 NVM Initialization
Purpose
This procedure may be needed when the machine cannot recover for some unknown reasons,
including problems such as producing blank copies/prints, Xerographic CRUs not recognized,
continuously giving system fault, etc.
Initial Actions to be taken:
Obtain all of the following information:
ï Disconnect any Foreign Interface Devices prior to performing this procedure.
ï NVM Value Factory Setting Report (Typically it is located in the Tray 1 pocket)
ï Any Customer Setting Auditron Account from the System Administrator
ï Any setting changes (specifically NVM settings) shown on the machineís service log.
ï Any Customer Settings in the Tools Mode.
Procedure
1. TBD.
Table 1 NVM Initialization
Name Description
IOT The following NVM locations will be initialized:
ï Chain 740 - links 020 through 419
ï Chain 741 - All
ï Chain 742 - links 055 through 079
ï Chain 744 - All
ï Chain 746 - All
ï Chain 753 - All
ï Chain 751 - All except links 168 and 364
ï Chain 760 - All
ï Chain 762 - All
ï Chain 764 - All
IIT/IPS The following NVM locations will be initialized:
ï Chain 715 - links 001 through 017
SYS-System The following NVM locations will be initialized:
ï Chain 700 - links 006, 065 through 070, 088, 116, 122, 127, 128, 147,
164 through 166, 174, 176 through 181, 197, 208
ï Chain 701 - links 912, 917, 924, 929
ï Chain 720 -link 002
ï Chain 730 - links 00 through 006
ï Chain 770 - links 124, 203
ï Chain 780 - links 065 through 068
ï Chain 785 - links 008, 009
ï Chain 790 - links 003, 004, 099
ï Chain 801 - links 104, 204, 304, 404, 504, 604, 704, 804, 904
ï Chain 802 - links 004, 104, 204, 304, 404, 504, 604, 704, 804, 904
ï Chain 803 - link 004
ï Chain 810 - links 002 through 019, 038 through 127
ï Chain 820 - links 003, 007 through 009, 017 through 019, 024, 026,
027, 029
ï Chain 823 - links 001 through 005, 008 through 011, 030 through 047
ï Chain 830 - links 001 through 004, 084, 085
ï Chain 850 - links 001 through 004, 007, 009 through 012, 015
ï Chain 860 - links 009, 013, 020, 025, 031, 032
SYS-User All user settable NVM locations in the following chains will be reset:
Chains 700, 780, 785, 790, 800, 801, 802, 803, 804, 805, 806, 810, 820,
823, 830, 840
All All of the above-listed NVM locations will be reset.
Table 1 NVM Initialization
Name Description
