6/02
4-93
DC1632/2240
REP 9.27
Repairs and Adjustments
Prelaunch Training/Review
REP 9.27 Retract Shaft
Parts List on PL 5.4
Replacement
NOTE: Cam and Flag must be aligned as shown, both on the same side (Figure 1).
Figure 1 Cam and Flag Alignment
Correct
Alignment
Incorrect
Alignment
