Xerox DocuColor 1632 Service Manual

6/02
4-139
DC1632/2240
REP 12.19
Repairs and Adjustments
Prelaunch Training/Review
REP 12.19 Finisher Rack Assembly
Parts List on PL 17.1
Removal
1. Remove Finisher (REP 12.4).
2. Loosen Feet (Figure 1).
Figure 1 Loosening Feet
3. Remove Bottom Plate (Figure 2).
Figure 2 Removing Bottom Plate
Loosen Feet
