Xerox DocuColor 1632 Service Manual

6/02
6-10
DC1632/2240
Prelaunch Training/Review
General Procedures and Information
dC131 NVM Tables
700-xxx ESS Configuration NVM List
Table 1 Chain 700
Chain-Link Name Default Range Description
700-006 Configuration - 0x00~0x08 [P, SP, CSP, CFSP] Set up at factory production. It allocates bits in the following P(rinter), F(ax), C(opy), S(can).
P = 0x01, F = 0x02, C = 0x04, S = 0x08.
700-073 Page Memory Size - 64*1024*102
4~256*1024*
1024
bytes (Auto Setting)
700-075 ART User Buffer Size 32KB 32*1024~204
8*1024
32KB~2048KB (32KB interval)
700-076 PostScript Buffer Size 8*1024*1024
~32*1024*10
24
Color machine = [8 MB~32 MB] B/W machine = [4.5 MB~32 MB] (0.25 MB interval)
700-078 Form Buffer Size 128 KB 128*1024~20
48*1024
128 KB~2048 KB
700-080 HPGL/Auto Layout Buffer Size 64 KB 64*1024~512
0*1024
64 KB~5120 KB (32 KB interval)
700-081 Parallel Buffer Size 64KB - 64 KB~1 MB (32 KB interval)
700-082 TBD 256KB 64*1024~1*1
024*1024
64 KB~1 MB (32 KB interval)
700-083 Lpd Buffer Size 256KB 64*1024~1*1
024*1024
64 KB~1 MB (32 KB interval)
700-084 NetWare Buffer Size 256KB 64*1024~1*1
024*1024
64 KB~1 MB (32 KB interval)
700-085 AppleTalk Buffer Size 256KB - 64 KB~1 MB (32 KB interval)
700-086 SMB Buffer Size 256KB 64*1024~1*1
024*1024
64 KB~1 MB (32 KB interval)
700-087 IPP Buffer Size 256KB 64*1024~1*1
024*1024
64 KB~1 MB (32 KB interval)
700-088 Salutation Buffer Size 256KB - 64 KB~1 MB (32 KB interval)
700-089 HDD Status - -2~0 0 = Yes, -1 = Error, -2 = No (Auto Detect)
700-120 Time Zone 540 - Displays the Time difference from GMT. E.g. Japan = 540, Hawaii = -600
700-124 Auto Clear Timer 1min 0~240 MF = 0, 1~4 = [Disable (0), 1~4min] (in increments of 1min) P = 0, 1~30 = [Disable (0), 1~30min] (in incre-
ments of 1min)
700-125 Job Cancel Timer 10min 0~5940 0 = Disable 240~5940 = 4~99min (in increments of 1min)
700-126 Operating Timer 10sec 0~240 0 = Disable 1~240 = [1~240sec] (in increments of 1sec)
700-127 Job End Timer 6sec 0~240 0 = Disable 1~240 = [1~240sec] (in increments of 1sec)
700-128 Scanning Timer 4sec 1~20 1~20 = [1~20sec (1sec unit)
700-129 LowPower Mode Timer 15 6~240 6~240 = [6~240min (in increments of 1min)]
700-130 Sleep Mode Timer 60min 15~240 15~240 = [15~240min (in increments of 1min)]
700-131 Sleep Mode Available 1 [Setup
Range] =
0 = Disable, 1 = Enable
