6/02
5-10
DC1632/2240
PL 2.1
Prelaunch Training/Review
Parts List
PL 2.1 Tray 1: 1 of 2
Item Part Description
1 003E23672 Stop
2 014E42850 Spacer
3 110K08541 Tray 1 Paper Size Sensor (REP
7.5)
4 050K48170 Tray 1 (REP 7.8)
5 – Cover (Not Spared)
6 892E41110 Label (1)
7 – Bracket (Not Spared)
