Xerox DocuColor 1632 Service Manual

6/02
2-254
DC1632/2240
15-376, 15-377
Prelaunch Training/Review
Status Indicator RAPs
15-376 X PIO Non-match Failure 1
Communication Failure.
Procedure
Switch the power off then on. The problem continues.
YN
Return to Service Call Procedures.
Check the connectors on the IIT/IPS PWB (PL 18.3) and the ESS PWB (PL 13.1). If the check
ia OK, replace the ESS PWB (PL 13.1). If the problem continues, replace the IIT/IPS PWB (PL
18.3).
15-377 X PIO Non-match Failure 2
Communication Failure.
Procedure
Switch the power off then on. The problem continues.
YN
Return to Service Call Procedures.
Check the connectors on the IIT/IPS PWB (PL 18.3) and the ESS PWB (PL 13.1). If the check
ia OK, replace the ESS PWB (PL 13.1). If the problem continues, replace the IIT/IPS PWB (PL
18.3).
