6/02
4-130
DC1632/2240
REP 12.14
Prelaunch Training/Review
Repairs and Adjustments
6. Move PWB Chassis (Figure 5).
Figure 5 Moving PWB Chassis
7. Remove Front Elevator Bracket (Figure 6).
Figure 6 Removing Elevator Belt Assembly
1
Release
Wires from
Clamp
2
Loosen
Screw
2
Remove
Screws
(2)
4
Move PWB
Chassis
Remove
Screws (3)
and Elevator
Belt Assembly
