746-012 2nd Output 368 0~921
(1bit= -4.888V)
For Component Control (0~- 4500V)
746-013 DTS Output 818 0~818
(1bit= -3.666V)
For Component Control (0~- 3000V)
746-017 Resistance detection calculation results
Y
51 31~255 (
1bit= 0.196µA)
Displays the output current corresponding to the resistance of the Primary Transfer part calculated from the volt-
age measured at fixed current (10 µA) in Y Color 1ST BTR.
746-018 Resistance detection calculation results
M
51 31~255
(1bit= 0.196µA)
Displays the output current corresponding to the resistance of the Primary Transfer part calculated from the volt-
age measured at fixed current (10 µA) in M Color 1ST BTR.
746-019 Resistance detection calculation results
C
51 31~255
(1bit= 0.196µA)
Displays the output current corresponding to the resistance of the Primary Transfer part calculated from the volt-
age measured at fixed current (10 µA) in C Color 1ST BTR.
746-020 Resistance detection calculation results
K
102 25~459
(1bit= 0.196µA)
Displays the output current corresponding to the resistance of the Primary Transfer part calculated from the volt-
age measured at fixed current (10 µA) in K Color 1ST BTR.
746-021 1ST BTR Output Remote Normal-
speed Y
86 0~200
(1bit= 1%)
For primary transfer output adjustment of Y Color at FC104mmsec. Displays the multiplication value in primary
transfer current of 746-017. ex., At 100 = Primary Transfer Current=14 µAx1.0=10 µA; At 150 = Primary Trans-
fer Current=14 µAx1.5=21 µA
746-022 1ST BTR Output Remote Normal-
speed M
86 0~200
(1bit= 1%)
For primary transfer output adjustment of M Color at FC104mmsec. Displays the multiplication value in primary
transfer current of 746-018. ex., At 100 = Primary Transfer Current=14 µAx1.0=10 µA; At 150 = Primary Trans-
fer Current=14 µAx1.5=21 µA
746-023 1ST BTR Output Remote Normal-
speed C
86 0~200 (1bit= 1%) For primary transfer output adjustment of C Color at FC104mmsec. Displays the multiplication value in primary
transfer current of 746-019. ex., At 100 = Primary Transfer Current=14 µAx1.0=10 µA; At 150 = Primary Trans-
fer Current=14 µAx1.5=21 µA
746-024 1ST BTR Output Remote Normal-
speed K
86 0~200 (1bit= 1%) For primary transfer output adjustment of K Color at FC104mmsec. Displays the multiplication value in primary
transfer current of 746-020. ex., At 100 = Primary Transfer Current=14 µAx1.0=10 µA; At 150 = Primary Trans-
fer Current=14 µAx1.5=21 µA
746-025 1ST BTR Output Remote Half-speed
FC Y
36 0~200 (1bit= 1%) For primary transfer output adjustment of Y Color at FC52mmsec. Displays the multiplication value in primary
transfer current of 746-017. ex., @ 50 = Primary Transfer Current=14 µAx0.5=7 µA
746-026 1ST BTR Output Remote Half-speed
FC M
36 0~200 (1bit= 1%) For primary transfer output adjustment of M Color at FC52mmsec. Displays the multiplication value in primary
transfer current of 746-018. ex., At 50 = Primary Transfer Current=14 µAx0.5=7 µA
746-027 1ST BTR Output Remote Half-speed
FC C
36 0~200 (1bit= 1%) For primary transfer output adjustment of C Color at FC52mmsec. Displays the multiplication value in primary
transfer current of 746-197. ex., At 50 = Primary Transfer Current=14 µAx0.5=7 µA
746-028 1ST BTR Output Remote Half-speed
FC K
36 0~200 (1bit= 1%) For primary transfer output adjustment of K Color at FC52mmsec. Displays the multiplication value in primary
transfer current of 746-020. ex., At 50 = Primary Transfer Current=14 µAx0.5=7 µA
746-029 1ST BTR Output Remote Twice-speed
BW K
186 0~255 (1bit= 1%) For primary transfer output adjustment of K Color at BW 194mmsec. Displays the multiplication value in primary
transfer current of 746-020
746-030 1ST BTR Output Remote Normal-
speed BW K
100 0~200 (1bit= 1%) For primary transfer output adjustment of K Color at BW 104mmsec. Displays the multiplication value in primary
transfer current of 746-020
746-031 1ST BTR Output Remote Half-speed
BW K
36 0~200 (1bit= 1%) For primary transfer output adjustment of K Color at BW 52mmsec. Displays the multiplication value in primary
transfer current of 746-020
746-032 1ST BTR Present Output Y 51 31~255
(1bit= 0.196µA)
Displays the Resistance Detection Calculation results * remote.
746-033 1ST BTR Present Output M 51 31~255
(1bit= 0.196µA)
Displays the Resistance Detection Calculation results * remote.
746-034 1ST BTR Present Output C 51 31~255
(1bit= 0.196µA)
Displays the Resistance Detection Calculation results * remote.
Table 10 Chain 746
Chain-Link Name Default Range Description
