DC1632/2240
4-341, 4-342
Prelaunch Training/Review
Status Indicator RAPs
4-341 IOT Logic
Operation failure of an MCU PWB operation.
Initial Actions
Re-installation the software.
Procedure
CH3.1A, CH3.6A
Connect black meter lead to ground or machine frame. There is +5VDC measured at J401-
B20
YN
There is +5VDC measured at j568-5
YN
There is +5VDC measured at j568-1
YN
Repair the wire between FS534 and j568-2.
Replace ROS Assembly (PL 3.1).
Check for an open circuit between j568-5 the p400-9.
If the circuit is OK, replace the MCU PWB (PL 13.1).
Replace MCU PWB (PL 13.1).
If the problem continues, replace ROS Assembly (PL 3.1).
4-342 Flash ROM Motion
Motion failure of Flash ROM
Procedure
Switch the power off then on. The problem continues.
YN
Return to Service Call Procedures.
Replace ROM PWB (PL13.1)
To Next Page
