Xerox DocuColor 1632 Service Manual

6/02
6-65
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
900-xxx ESS Tag-Matrix NVM List
870-038 PH = 3TM 2Tray NMBR of Feeds pre-
vious value
- - 0~99999999
870-039 PH = 3TM 3Tray NMBR of Feeds pre-
vious value
- - 0~99999999
870-040 PH = 3TM 4Tray NMBR of Feeds pre-
vious value
- - 0~99999999
870-041 PH = 1TM 2Tray NMBR of Feeds previ-
ous value
- - 0~99999999
870-042 PH = TTM 2Tray NMBR of Feeds pre-
vious value
- - 0~99999999
870-043 PH = TTM 3Tray NMBR of Feeds pre-
vious value
- - 0~99999999
870-044 PH = TTM 4Tray NMBR of Feeds pre-
vious value
- - 0~99999999
870-045 PV (CV) Counter for FILTER Life previ-
ous value
- - 0~99999999
Table 24 Chain 870
Chain/Link Name Default Range Description
Table 25 Chain 900
Chain/Link Name Default Range Description
900-001 Tag 1V 0 0~1 Tag Information 1V
900-002 Tag 2V 0 0~1 Tag Information 2V [0 = OFF, 1 = ON]
900-003 Tag 3V 0 0~1 Tag Information 3V [0 = OFF, 1 = ON]
900-004 Tag 4V 0 0~1 Tag Information 4V [0 = OFF, 1 = ON]
900-005 Tag 5V 0 0~1 Tag Information 5V [0 = OFF, 1 = ON]
900-006 Tag 6V 0 0~1 Tag Information 6V [0 = OFF, 1 = ON]
900-007 Tag 7V 0 0~1 Tag Information 7V [0 = OFF, 1 = ON]
900-008 Tag 8V 0 0~1 Tag Information 8V [0 = OFF, 1 = ON]
900-009 Tag 9V 0 0~1 Tag Information 9V [0 = OFF, 1 = ON]
900-010 Tag 10V 0 0~1 Tag Information 10V [0 = OFF, 1 = ON]
900-011 Tag 11V 0 0~1 Tag Information 11V [0 = OFF, 1 = ON]
900-012 Tag 12V 0 0~1 Tag Information 12V [0 = OFF, 1 = ON]
900-013 Tag 13V 0 0~1 Tag Information 13V [0 = OFF, 1 = ON]
900-014 Tag 14V 0 0~1 Tag Information 14V [0 = OFF, 1 = ON]
900-015 Tag 15V 0 0~1 Tag Information 15V [0 = OFF, 1 = ON]
900-016 Tag 16V 0 0~1 Tag Information 16V [0 = OFF, 1 = ON]
900-017 Tag 17V 0 0~1 Tag Information 17V [0 = OFF, 1 = ON]
900-018 Tag 18V 0 0~1 Tag Information 18V [0 = OFF, 1 = ON]
900-019 Tag 19V 0 0~1 Tag Information 19V [0 = OFF, 1 = ON]
900-020 Tag 20V 0 0~1 Tag Information 20V [0 = OFF, 1 = ON]
900-021 Tag 21V 0 0~1 Tag Information 21V [0 = OFF, 1 = ON]
