Xerox DocuColor 1632

6/02
2-59
DC1632/2240
4-414, 4-415
Status Indicator RAPs
Prelaunch Training/Review
4-414 IBT Belt Cleaner
IBT Belt Cleaner near end of life.
Procedure
Replace the Cleaner Assembly. The problem continues.
YN
Return to Service Call Procedures.
Replace the MCU PWB (PL 13.1).
If the problem continues, replace the MCU NVM PWB (PL 13.1)
4-415 2nd BTR Unit
It is time to replace the 2nd BTR UNIT.
Procedure
Replace the 2nd BTR Unit. The problem continues.
YN
Return to Service Call Procedures.
Replace the MCU PWB (PL 13.1).
If the problem continues, replace the MCU NVM PWB (PL 13.1)
