Xerox WorkCentre 6505 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only I – 3
Index
E
EEPROM Board, 2-39
location, 2-38
part number, MFP, 9-38
part number, SFP, 9-32
removal, MFP, 8-161
removal, SFP, 8-139
Electrostatic discharge (ESD), 2-xix
Email Address Book List, A-12
Embedded Pages, A-4 to A-13
Engine test print, 4-47, 5-44
Environmental specifications, 1-22
Erase LED
operation, 2-35
part number, 9-22
removal, 8-97
testing, 4-35
Error Code
Listing and Summary, 3-6 to 3-34
Troubleshooting, 3-35 to 3-164
Error history
system failure, 3-2
Error History Report, A-7
accessing, 3-2
Error Message & Code Summary, 3-6 to 3-34
Error Message Abbreviations, 3-5
Errors, POST, 4-6
Excess toner collection, 2-53
Exit Roller
location, 2-31
Exit Sensor
location, 2-31
operation, 2-31
troubleshooting, 4-23
F
Fan, 2-38
location, 2-38
part number, MFP, 9-36
part number, SFP, 9-30
removal, MFP, 8-141
removal, SFP, 8-119
testing, 4-32
Fasteners, 8-5
Fax
operation, 2-71
Specifications, 1-20
standards, 2-73
Fax Board
location, 2-38
part number, 9-34
removal, 8-143
Fax/Scanner Diagnostic Menu Map, 4-11
Fax/Scanner Diagnostic Tests, 4-51
FB (flatbed) Motor Test, 4-64
Feed Drive Assembly, 2-36, 2-50
color mode switching, 2-36
location, 2-36
part number, 9-28
removal, 8-117
Feed Motor, 2-24
Feed Roller, 2-23
operation, 2-23
part number, 9-19
removal, 8-9
Feed Solenoid, 2-23
Kit part number, 9-17, 9-54
operation, 2-23
removal, 8-49, 8-50
testing, 4-34
Feeder
components, 2-22
feed roller
operation, 2-23
feed solenoid
operation, 2-23
part number, MFP & SFP, 9-17
removal, 8-72
Feeder Assembly
removal, 8-73
Feeder Board, 2-24
Ferrite Core
part number, 9-45
Firmware
update boot firmware, A-16
update main firmware, A-17
FPOT, 1-24
Front Cover
location, MFP, 1-5
location, SFP, 1-4
part number, MFP, 9-12
part number, SFP, 9-8
removal, MFP, 8-33
removal, SFP, 8-22
Front Cover Pivot Shaft, SFP
part number, 9-8
Front Door Retainer Strap removal, MFP, 8-41
Front USB Assembly
removal, 8-158
Front USB Assy
part number, 9-45
Fuser
cooling down, 2-46
drive transmission, 2-49
exit sensor, 2-31
life count, 6-10
location, MFP, 1-9
location, SFP, 1-8
operation, 2-31
part number, 9-26
removal, 8-10
reset life counter, 6-5
temperature
sensing, 2-18
temperature control, 2-46
unfused image, 5-36
warm up, 2-46

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
