Anritsu MS2026C - Trace Header Transfer (Continued)

Trace Subsystem VNA Commands
3-164 PN: 10580-00306 Rev. E MS20xxC PM
Trace Header Transfer (continued)
Table 3-13. Trace Header Marker Parameters
Markers Parameter Name Description
MKR_MWVNA_Xx Marker x X value (where x is the marker number 1 to 8)
MKR_MWVNA_POINTx Marker x display point
MKR_MWVNA_REALx Marker x Real value
MKR_MWVNA_IMAGx Marker x Imaginary value
MKR_MWVNA_READOUTx Marker x readout style. Available readout styles are:
Graph = 0
Log Mag = 1
Log Mag and Phase = 2
Phase = 3
Real and Imaginary = 4
SWR = 5
Impedance = 6
Admittance = 7
Normalized Impedance = 8
Normalized Admittance = 9
Polar Impedance = 10
Group Delay = 11
Log Mag/2 = 12
Lin Mag = 13
Lin Mag and Phase = 14
MKR_MWVNA_FLAGSx Marker x flags:
MWVNA_MARKER_REF_BIT ............ 0x00000001
MWVNA_MARKER_DELTA_BIT .......... 0x00000002
MWVNA_MARKER_ALL_BIT ............ 0x00000004
MWVNA_MARKER_INIT_BIT ........... 0x00000008
MWVNA_MARKER_ZERO_SPAN_BIT ...... 0x00000010
MWVNA_MARKER_OUT_OF_RANGE_BIT ... 0x00000020
MKR_TRACEx Specifies to which trace the marker x is attached
MKR_DELTA_TOx Specifies to which trace the marker x is delta
