Trace Header Transfer (continued)
Table 3-14. Trace Header Limits Parameters
Limits Parameter Name Description
LIMIT_MWVNA_FLAGS_UPx
LIMIT_MWVNA_FLAGS_LOx
Upper(UP)/Lower(LO) Limit flags for trace x:
LIMIT_LEFT_OF_SCREEN .... 0x00000001
LIMIT_RIGHT_OF_SCREEN ... 0x00000002
LIMIT_IS_ON ............. 0x00000004
LIMIT_IS_RELATIVE ....... 0x00000008
LIMIT_ALARM_IS_ON ....... 0x00000010
LIMIT_LIMIT_UNITIALIZED . 0x00000020
LIMIT_MESSAGE_ON ........ 0x00000040
LIMIT_MWVNA_POINT_UPx_#
LIMIT_MWVNA_POINT_LOx_#
Upper/Lower Limit point value for trace x, where #
is the limit point number. Each point value contains
the X-axis value, Y-axis value, limit point, and limit
flags, separated by a space.
Note: Limit point and limit flags are not currently
used and always returns a value of 0.000000 for
limit point and 0 for limit flags.
LIMIT_MWVNA_GRAPH_TYPE_UPx
LIMIT_MWVNA_GRAPH_TYPE_LOx
Upper/Lower Limits Graph type. For available
graph types, refer to “GRAPH_TYPE”.
LIMIT_MWVNA_TOTAL_POINTS_UPx
LIMIT_MWVNA_TOTAL_POINTS_LOx
Upper/Lower Limit total points.
