LabVIEW™ Example
A-10 PN: 10580-00306 Rev. E MS20xxC PM
A-5 LabVIEW™
This example shows how to read the trace data from the instrument in 32-bit integer format.
The output is an array of data point magnitudes. Figure A-1 on page A-11 shows the data
capture and conversion to 32-bit integers in the format used by LabVIEW. Figure A-2
on page A-12 shows the details of the conversion.
Note
Your instrument must first be defined to the VISA resource manager using
NI-MAX. The VISA resource for your instrument serves as the VISA resource input
to the vi.
