Power Monitor Commands :FETCh:PMONitor Subsystem
MS20xxC PM PN: 10580-00306 Rev. E 5-9
5-8 :FETCh:PMONitor Subsystem
This subsystem contains commands to fetch the power monitor reference power level data,
zero power level data and the displayed power level data.
Displayed Data
:FETCh:PMONitor:DATA?
Title: Displayed Data
Description: Fetches the displayed power level data. The returned value is returned
in the units that have been set with the Units command
(:CALCulate:PMONitor:UNITs DBM|WATT|DB|PERCent).
If units are in dBm, then the returned value is in dBm.
If units are in percent, then the returned value is in percent.
If units are in dB, then the returned value is in dB.
If units are in watts, then the returned value is in
0.1 uW (0.1 microwatt) increments. For example:
Syntax: :FETCh:PMONitor:DATA?
Cmd Parameter: NA (query only)
Query Response: <NR3> (depends on set unit)
Example: To fetch the displayed power level data:
:FETCh:PMONitor:DATA?
Front Panel
Access: NA
Table 5-5. :FETCh:PMONitor Subsystem
Keyword Parameter Data or Units
:FETCh
:PMONitor
:RELative Refer to “:FETCh:PMONitor:RELative Subsystem” on page 5-10
:ZERO Refer to “:FETCh:PMONitor:ZERO Subsystem” on page 5-11
Returned Value Measurement Value
1 0.1 microwatt
10 1 microwatt
25000 2500 microwatts or 2.50 milliwatts
12000000 1200000 microwatts or 1.2000000 watts
