Chapter 3 — VNA Commands
3-1 Introduction
This chapter describes commands for Vector Network Analyzer mode. Only the commands
that are listed in this chapter and in Chapter 8, “All Mode Commands” can be used in Vector
Network Analyzer mode. Using commands from other modes may produce unexpected
results.
Notational conventions are described in Section 2-10 “Command and Query Notational
Conventions” on page 2-12.
VNA Commands
Note
Front Panel Access in VNA mode via the function hard keys may be listed as
Freq/Time/Dist, as Freq/Dist, or as Freq. The first function hard key is displayed
with the label Freq/Time/Dist when Option 2 is installed in the VNA Master and with
the label Freq/Dist when Option 501 is installed in the VNA Master.
Table 3-1. VNA Commands Subsystems
Keyword Parameter Data or Units
:CALCulate{1-4} “:CALCulate Subsystem” on page 3-2
:DISPlay “:Display Subsystem” on page 3-81
:FORMat “:Format Subsystem” on page 3-88
:INITiate “:INITiate Subsystem” on page 3-89
:INPut “:INPut Subsystem” on page 3-91
:MMEMory “:MMEMory Subsystem” on page 3-96
[:SENSe] “[:SENSe] Subsystem” on page 3-101
:SOURce “:SOURce Subsystem” on page 3-148
:STATus “:STATus Subsystem” on page 3-152
:SYSTem “:SYSTem Subsystem” on page 3-153
:TRACe “Trace Subsystem” on page 3-153
