:TRACe VVM Subsystem Vector Voltmeter Commands
4-10 PN: 10580-00306 Rev. E MS20xxC PM
VVM_CABLE Selected Cable number 1 to 12
VVM_PORT_X_SAVE_RETURN_REF Saved status for Port x Return reference,
where x = 1 or 2
VVM_PORT_X_SAVE_INSERTION_REF Saved status for Port x Insertion reference,
where x = 1 or 2
VVM_PORT_X_RETURN_REF_AMP Return reference amplitude for Port x,
where x = 1 or 2
VVM_PORT_X_RETURN_REF_PHASE Return reference phase for Port x,
where x = 1 or 2
VVM_PORT_X_RETURN_REF_VSWR Return reference VSWR for Port x,
where x = 1 or 2
VVM_PORT_X_RETURN_REF_REAL Return reference real for Port x,
where x = 1 or 2
VVM_PORT_X_RETURN_REF_IMAG Return reference imaginary for Port x,
where x = 1 or 2
VVM_PORT_X_INSERTION_REF_AMP Insertion reference amplitude for Port x,
where x = 1 or 2
VVM_PORT_X_INSERTION_REF_PHASE Insertion reference phase for Port x,
where x = 1 or 2
CAL_PORT Port # (where 0 is Port 1, and 1 is Port 2)
Table 4-4. Trace Header Parameters (Sheet 2 of 2)
Parameter Name Description
