All Mode Commands :INSTrument Subsystem
MS20xxC PM PN: 10580-00306 Rev. E 8-3
1 = SPA (Spectrum Analyzer mode)
10 = HI_PM (High Accuracy Power Meter mode, Option 19)
14 = IA (Interference Analysis, Option 25)
15 = CS (Channel Scanner, Option 27)
26 = MWVNA (Vector Network Analyzer mode)
101 = Power Monitor (Power Monitor mode, Option 5)
102 = VVM (Vector Voltmeter mode, Option 15)
Related Command: :INSTrument:CATalog:FULL?
:INSTrument[:SELect]
:STATus:OPERation?
Front Panel
Access: Shift-9 (Mode)
Note
Switching modes can take longer than 60 seconds, depending on the application.
Anritsu Company advises you to set the remote PC time-out to 120 seconds in
order to avoid unexpected time-out errors.
