3 Data Log Settings Dialog Box
14
Data Log Function
■ Words
Reads the value of specified number of word device address from Top Device Address and output as CSV. Specifies
the number of word devices to read (1 to 128).
This is displayed only when String(S) is selected for Data Type.
Example: When Number of Data is 2, Top Device Address of the data to register to Data Number 1 is LDR0000,
and Words is 3
Device addresses used in Data Number 1: LDR0000, LDR0001, LDR0002
Device addresses used in Data Number 2: LDR0003, LDR0004, LDR0005
LDR0003 is registered as the starting device address of Data Number 2.
■ Display Type
Sets the display type for numerical values when data is output as CSV.
This is displayed only when UBIN16(W), BIN16(I), UBIN32(D), BIN32(L), BCD4(B), BCD8(EB), or
Float32(F) is selected for Data Type.
Counting Method: Select the display type as Decimal or Hexadecimal for numerical values.
Digits: Specifies the digits to display. The range of digits that can be set varies based on the
display type and data type. The digits that can be set are as follows.
Display Type Data Type Digits
Decimal display
UBIN16(W), BIN16(I) 1 to 5
UBIN32(D), BIN32(L) 1 to 10
BCD4(B) 1 to 4
BCD8(EB) 1 to 8
Float32(F) 1 to 10
Hexadecimal display
UBIN16(W) 1 to 4
UBIN32(D) 1 to 8
Display Floating Point: Select this check box to display the decimal point.
When the Display Floating Point check box is selected and UBIN16(W), BIN16(I), UBIN32(D),
BIN32(L), BCD4(B), or BCD8(EB) is selected for Data Type, the source device is an integer, but the
value is output with the decimal point added at the configured floating digits.
However, if Float32(F) is selected for Data Type, the source data is a decimal value.
Floating Digits: Specifies the number of digits for the fractional part of the decimal value out of the
number of digits specified by Digits.
This option can only be configured when the Display Floating Point check box is selected.
The range of digits that can be set for the fractional part varies based on the display type and
data type. The range of digits that can be set for the fractional part is as follows.
Display Type Data Type Floating Digits
Decimal display
UBIN16(W), BIN16(I) 1 to Digits
UBIN32(D), BIN32(L) 1 to Digits
BCD4(B) 1 to Digits
BCD8(EB) 1 to Digits
Float32(F) 1 to Digits or 8
Hexadecimal display
UBIN16(W) --
UBIN32(D) --
Floating Symbol:
Selects the decimal point symbol from the following.
.(dot), :(colon), ;(semicolon), ,(comma), /(slash)
This option can only be configured when the Display Floating Point check box is selected.
Example: When Digits is 4 and Floating Digits is 2
When Floating Symbol is .(dot) 12.34
When Floating Symbol is /(slash) 12/34
