2 Text Groups and Text Configuration Procedure
19-4 WindO/I-NV4 User’s Manual
4 Under Text Group Name, enter the name for the text group.
The maximum number for the Text Group Name is 20 characters.
5 Click OK.
The Text Group Settings dialog box closes.
For one text group, proceed to step
8.
6 Repeat steps 3 through 5 to create the necessary text group.
7 With Change Text Group by Device Address, specify the word device as the condition to switch the text group.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
These options can only be configured when Number of Text Groups is specified as two or more.
8 With (Font), select the font to use for the text to register from the following.
Western, Japanese, Simplified Chinese, Traditional Chinese, Hangul, Central European, Baltic, Cyrillic,
Windows
9 With (Text Color), select the color of the text to register (color: 256 colors, monochrome: 16 shades).
Click Color to display the Color Palette. Select a color from the Color Palette.
To use when the MICRO/I power is turned on or switched to Run Mode, select the Use this Text Group as
Default check box.
The text group displayed with in Text Manager is the default.
When the value of device address is 0, the text group switches to the text group set as the default.
If the value of device address is invalid, the text group is not switched.
When Windows is selected, all the fonts installed on the computer can be used. This allows you to display
fonts and languages that are not installed on the MICRO/I.
Click Change to display the Font Settings dialog box. Configure the details such as the font, style, and size.
For details, refer to Chapter 2 “Windows Font” on page 2-13.
(Font)
(Text Color)
To Next Page
