WindO/I-NV4 User’s Manual 21-3
2 Sound Function Configuration Procedure
21
Sound Function
4 Double click the cell under Save To and select the save destination for the sound file.
■ Internal Memory
Saves the sound file to internal memory.
■ External Memory Device
Saves the sound file to external memory device
*1
inserted in the MICRO/I.
5 Double click the cell under Trigger Condition and select Device Address.
6 Specify the device address that will trigger playing the sound file in Trigger Device Address.
Double-click the cell or click the cell and then click in the Trigger Device Address column to select a device
address from the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address
Settings” on page 2-70.
7 Configure Repeat, Change Volume Level
*2
, and any other options, and then click OK.
The Sound Settings dialog box closes.
This concludes the configuration to play a sound file when a value of device address changes to 1.
●
To play a sound file as a touch sound instead of a beep.
1 On the Configuration tab, in the System Setup group, click Sound.
The Sound Settings dialog box is displayed.
2 Double-click the cell in the File Name column to register a sound file.
The Open dialog box is displayed.
*1 USB flash drive inserted in USB1 for HG2J-7U, SD memory card for HG5G/4G/3G-V and HG4G/3G
*2 HG5G/4G/3G-V, HG4G/3G only
The procedures to save the sound file to the external memory device are as follows.
• On the Home tab, click the arrow under Download, and click Project Data to display the Download
dialog box. Select the Sound Files check box of Download following files to External Memory
Device, and click OK.
• On the Home tab, click the arrow under Download, and click Files to External Memory Device to
display the Open dialog box. Specify a sound file and click Open.
To Next Page
