6 System Information
24-32 WindO/I-NV4 User’s Manual
■ Operator Interface Project Information
■ Opened Project Information
Font/Kanji Dictionary Data Information Dialog Box
This dialog box is used to check the state of installed optional fonts and the Kanji dictionary data.
The installation status of each optional font and the Kanji dictionary data are shown to the right of the font.
The following additional fonts can be installed.
• Japanese Large Font (First standard)
• Japanese Large Font (Second standard)
• Simplified Chinese
• Traditional Chinese
• Hangul
• European Large Font
• Central European
• Baltic
• Cyrillic
Project Name: Displays the project name of projects downloaded to the MICRO/I.
Modified: Displays the time that project data downloaded to the MICRO/I was last saved
in WindO/I-NV4.
WindO/I-NV4 Version: Displays the version of WindO/I-NV4 used to create the project data
downloaded to the MICRO/I.
Communication Driver Information: Checks the communication driver configured in the project downloaded to the
MICRO/I.
Click this button to display the Target Communication Driver Information
dialog box. For details, refer to “Communication Driver Information Dialog
Box” on page 24-34.
Project Name: Displays the project name of the project being edited.
Modified: Displays the time that the project being edited was last saved in WindO/I-NV4.
WindO/I-NV4 Version: Displays the version of WindO/I-NV4 used to create the project being edited.
This function can be used to show information about a project that is being edited and simultaneously check
information about project data downloaded to the MICRO/I.
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
HG2J-7U
