3 FTP Client Function
28-22 WindO/I-NV4 User’s Manual
3 Configure each items of the FTP server.
■ FTP server settings
■ Advanced Setting
Specifies the FTP server settings by the values of the device addresses. The settings for the FTP server settings can
be used as initial values. For details, refer to “Individual Settings Dialog Box” on page 28-28.
4 Click OK to close the Individual Settings dialog box.
You are returned to the FTP Server Manager.
5 Repeat steps 2 through 4 to configure the necessary FTP server.
6 Click OK.
This concludes the FTP server configuration.
*1 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P only
Server Name: Enter a name of the FTP server. The maximum number is 40 characters.
The default is "FTPServern". (n: The number in the FTP Server Manager)
Host Name: Select this option and enter the host name when specifying the FTP server with a host name.
The maximum number is 40 characters. Only alphanumeric characters and symbols can be used.
IP Address: Select this option and enter the IP address when specifying the FTP server with an IP address.
The format is “xxx.xxx.xxx.xxx”. “xxx” stands for a numeric value from 0 to 255.
User Name: Enter the name of the user account for the FTP server.
The maximum number for the user name is 40 characters. Only alphanumeric characters and
symbols can be used.
Password: Enter the password for the FTP server.
The maximum number for the user name is 40 characters. Only alphanumeric characters and
symbols can be used.
Port Number: Specifies the port number for the FTP server (0 to 65535).
Transfer Mode: Selects the transfer mode of the FTP server.
Pasv: Uses passive mode for the data connection.
Active: Uses active mode for the data connection.
Connection Timeout
*1
:
Specifies the timeout period (10 to 300 seconds) until the connection to server is automatically aborted.
After the Trigger Condition in the File Transfer Settings is satisfied, if there is no response from the
FTP server which is tried to connect, the MICRO/I will automatically cancel to connect.
The Connection Timeout for HG2J-7U is 10 seconds.
Transfer Timeout: Specifies the timeout period until the process of transferring files is automatically canceled.
After the Trigger Condition in the File Transfer Settings is satisfied and the data
connection is available, if there is no response from the FTP server, the MICRO/I will
automatically cancel to transfer files.
HG2J-7U: 1 to 60 minutes
HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P: 10 to 300 seconds
