WindO/I-NV4 User’s Manual 28-29
3 FTP Client Function
28
Maintenance
■ Advanced Setting
Allocation of Address Number when the FTP Server Settings are specified by Value of Device Address
When the Specify FTP Server Settings by Value of Device Address check box is selected, it allocates the
settings of the FTP Server Settings starting at the device address set in the Top Device Address. The details are
shown below.
*1 When IP address is selected, use only four words from the beginning, and the remaining seventeen words are left as a
reserved area.
*2 The twenty-first word is recognized as a NULL terminating character (0x00) regardless of the value of device address.
*3 Add a NULL terminating character (0x00) as the end of the string data when the string length is less than twenty words.
Specify FTP Server Settings by Value of Device Address: Select this check box to set the FTP Server Settings
using the value of the specified device address.
Top Device Address: Specify the word device to use. It allocates the settings of the FTP Server Settings starting
at the configured device address. You can only specify an internal device.
Click to display the Tag Editor. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-70.
Copy the settings as default value to Device Address: Select this check box to copy the settings in the FTP
Server Settings to device addresses as default.
(Device Address): Specifies the bit device or the bit number of the word device that triggers the copy of the
settings.
When the value of device address changes from 0 to 1, the values configured in the FTP
Server Settings are written, beginning from the device address set by the Top Device
Address.
Click to display the Tag Editor. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-70.
Settings Address Number Words Data Format
FTP Server +0 to +20
21
*1,*2
Host Name is selected: String
IP Address is selected: Decimal
User Name +21 to +41
21
*2, *3
String
Password +42 to +62
21
*2, *3
String
Port Number +63 1 Decimal
Transfer Mode +64 1 Decimal
Connection Timeout (second units) +65 1 Decimal
Transfer Timeout (second units) +66 1 Decimal
String data is stored in the upper byte and lower byte according to the Storage Method of String Data
setting. For details, refer to Chapter 4 “Storage Method of String Data” on page 4-29.
To Next Page
