WindO/I-NV4 User’s Manual 28-75
5 Social Media Function
28
Maintenance
● Insert Value of Device Address Dialog Box
To enter a value of device address in the body text of the social media message, configures the settings om the Insert
Value of Device Address dialog box.
■ Reference Device Address
Specify the source word device.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
■ Display Type
Selects the display type of the value from the following.
Decimal, Hexadecimal, Character
■ Data Format
Data Type: Selects the type of data for the value.
For details, refer to Chapter 2 “1.1 Available Data” on page 2-1.
This setting can only be configured when Decimal or Hexadecimal is selected for
Display Type.
Digits: Specifies the digits to display. The range of digits that can be set varies based on the
display type and data type. The digits that can be set are as follows.
Display Type Data Type Digits
Decimal display
UBIN16(W), BIN16(I) 1 to 5
UBIN32(D), BIN32(L) 1 to 10
BCD4(B) 1 to 4
BCD8(EB) 1 to 8
Float32(F) 1 to 10
Hexadecimal display
UBIN16(W) 1 to 4
UBIN32(D) 1 to 8
Display Floating Point: Select this check box to display the decimal point.
This setting can only be configured when Decimal is selected for Display Type.
When the Display Floating Point check box is selected and UBIN16(W), BIN16(I), UBIN32(D),
BIN32(L), BCD4(B), or BCD8(EB) is selected for Data Type, the source device is an integer, but the
value is displayed with the decimal point added at the configured floating digits.
To Next Page
